12V100Ah lead acid battery

1. Small Internal Resistance 2. More Better Quality, More Better Consistency 3. Good Discharge, Long Life 4. Low temperature resistant 5. Stringing Walls Technology Will Transport Safer.

Send Inquiry PDF Download

Product Description

Short Description:

The lead acid gel technology used in this battery ensures exceptional performance and longevity. It is designed to withstand deep discharges and provide consistent power output over its lifespan. This makes it an ideal choice for demanding applications where reliability is paramount.

Model Number: MF12V100Ah

Name: 12V 100Ah Sealed Lead Acid Battery

Battery Type: Deep Cycle Sealed Gel

Cycle Life: 50%DOD 1422 times

The discharge rate: C10/C20

Warranty: 3years

product-1080-1299

Application

Deep cycle maintenance free gel battery.Our products can be used in UPS,solar street light,solar power systems,wind system,alarm system and telecommunications etc.

In addition to its performance, this battery is also designed with convenience in mind. Its maintenance-free design means you can install it and forget about it, without the need for regular maintenance or monitoring. This makes it an ideal choice for applications where ease of use is a priority.

product-750-750

Parameters

Cell Per Unit	6
Voltage Per Unit	12V
Capacity	100AH@10hr-rate to 1.80V per cell @25°c
Weight	31KG
Max. Discharge Current	1000 A (5 sec)
Internal Resistance	3.5 M Omega
Operating Temperature Range	Discharge: -40°c~50°c
	Charge: 0°c~50°c
	Storage: -40°c~60°c
Normal Operating	25°c±5°c
Float charging	13.6 to 14.8 VDC/unit Average at 25°c
Recommended Maximum Charging Current	10 A
Equalization	14.6 to 14.8 VDC/unit Average at 25°c
Self Discharge	Batteries can be stored for more than 6 months at 25°c. Self-discharge ratio less than 3% per month at 25°c. Please charge batteries before using.
Terminal	Terminal F5/F11
Container Material	A.B.S. UL94-HB, UL94-V0 Optional
